Multi-SLED Optical Spectral Engine (OSE2)

Lasers

The Multi-Channel Superluminescent Diode Light Source (OSE2) is a compact broadband source operating in the near-infrared range.

Contact Us

The Multi-Channel Superluminescent Diode Light Source (OSE2) is a compact broadband source operating in the near-infrared range. Packaged in a 32-pin butterfly, it integrates up to six SLEDs, each with independent monitoring, a common thermoelectric cooler (TEC), and an isolator for stable operation. Using DAYY’s spectral stitching technology, the OSE2 delivers extensive spectral coverage with reliable power stability, making it an adaptable solution for testing, imaging, and optical sensing applications.

not sure what fits?

Let us help you

We love to solve this puzzle and find the right fit.

Contact Us!

Heading for types of this product

Green Architecture

Evermind™ template is crafted like sustainable structures — clean, scalable, and built to last.

Precision Engineering

Every layout and component is tuned with variables and pixel-perfect details, so your brand stands on solid ground.

Dynamic Interactions

From nature-inspired transitions to fluid page structures, Evermind™ feels alive yet quietly sophisticated.

Green Architecture

Evermind™ template is crafted like sustainable structures — clean, scalable, and built to last.

Precision Engineering

Every layout and component is tuned with variables and pixel-perfect details, so your brand stands on solid ground.

Dynamic Interactions

From nature-inspired transitions to fluid page structures, Evermind™ feels alive yet quietly sophisticated.

Key Features

Between two and six superluminescent diodes (SLEDs) in a single unit
All SLEDs can be run from 0-100% of maximum rating
Fiber-coupled output power from 10mW to 40mW, Free Space output power from 30mW to 130mW
Bandwidth FWHM from 40nm to 460nm
SLEDs ranging from 770nm to 1680nm
DAYY’s technology for spectral stitching provides optimum power and bandwidth
Each SLED comes with a built-in independent monitor photodiode and one common thermoelectric cooler (TEC) for all SLEDs
Light output: FC/APC Connector (Optional FC/PC or SMA)

‍

Key Features

Between two and six superluminescent diodes (SLEDs) in a single unit
All SLEDs can be run from 0-100% of maximum rating
Fiber-coupled output power from 10mW to 40mW, Free Space output power from 30mW to 130mW
Bandwidth FWHM from 40nm to 460nm
SLEDs ranging from 770nm to 1680nm
DAYY’s technology for spectral stitching provides optimum power and bandwidth
Each SLED comes with a built-in independent monitor photodiode and one common thermoelectric cooler (TEC) for all SLEDs
Light output: FC/APC Connector (Optional FC/PC or SMA)

‍

Key Features

Between two and six superluminescent diodes (SLEDs) in a single unit
All SLEDs can be run from 0-100% of maximum rating
Fiber-coupled output power from 10mW to 40mW, Free Space output power from 30mW to 130mW
Bandwidth FWHM from 40nm to 460nm
SLEDs ranging from 770nm to 1680nm
DAYY’s technology for spectral stitching provides optimum power and bandwidth
Each SLED comes with a built-in independent monitor photodiode and one common thermoelectric cooler (TEC) for all SLEDs
Light output: FC/APC Connector (Optional FC/PC or SMA)

‍
